| ODEL |
4LZ-2.5AAW70G |
|
| Dimension |
Overall length(mm) Overall width(mm) Overall height(mm) |
5040 2285 2535 |
| Weight (kg) |
2935 |
|
| Engine |
Model Pattern rated output/speed (ps[kw]/rpm) |
4TNV98 Vertical 4 cylinder 4 stroke water-cooled direct injection turbo diesle 70[51.5]/2500 |
| Travel unit |
track width×length(mm) transmission mode Speed grade Running speed Advance(m/s) turning way |
425×1660 Hytrostatic stepless change[HST] Stepless vice-speed 3files Low speed:0~0.93 cruising speed:0~1.5 high speed:0~1.85 Brake change |
| Harvest unit |
Fu wo method rotation diameter*width(mm) transmission mode up and down adjustment Harvesting width(mm) cutter width(mm) Harvest height(mm) Lodging adaptive(degree) |
Fu wo machine 900*1920 Constant speed hytraulic 2060 1905 More than 40 [tip cutter] < 85 degeree, < 70 degree |
| Threshing unit |
Threshing system Diameter*width(mm) Concavity net area(4)(m2) |
Axial flow type threshing gear 640×1850 1.621 |
| cereal discharge unit |
capacity(L) cereal ejection port number(piece) Ejection method |
1030 2 In bag |
| Suitable crops Operational efficiency (a unit of area/ hour) |
Rice wheat rape 7.5 |
